EQUIPMENT APPEARANCE

xxxi

NCD-2364 DISPLAY UNIT

With Sun Cover

Note: When you remove the sun cover do the thumb position

push and the fingertip position pull at the same time action.

Front Panel

Desk Top Mount

Function Buttons

USB/ Chart Card

LCD Monitor

Sun Cover

Fingertip position

Thumb position
