Chapter 1 INSTALLATION

Fig. 1-4-1-4

 Close radome

Attach the radome. Set to fit the triangle mark of the upper and lower radome.

Fig. 1-4-1-5

Clamp the cable Connect cable mesh wire as Ground.

Like this

In the following order, on the diagonal, tighten gradually

in order to press uniformly packing.

The proper fastening torque of the fitting bolts (M5) is

102.96 N•cm (10.5kgf•cm).

6-M5 (stainless steel) bolt

Tightening torque: 10.5 kgf/cm
