6-5 Section 6 Settings
5
6
[Plot] tab (normal track)
The following table lists the settings when [Standard] is selected for [Track type] on the [Plot] tab.
Setting item
Description
Setting value
[Track type] combo box
Select a type of own track.
Standard: Normal track. It can be displayed
without the plotter option.
For the case when [Depth] is selected, see
the ‘[Plot] tab (depth track)’ section.
For the case when [Temperature] is
selected, see the ‘[Plot] tab (temperature
track)’ section.
Standard / Depth /
Temperature
[Plot Colour] combo box Select a colour of own track.
White / Grey / Amber /
Magenta / Blue / Cyan /
Green / Yellow / Orange /
Dark Red
[Plot Interval] combo box
(own track plot)
Select a plot interval.
Off/3 s/5 s/10 s/30 s/
1 min/3 min/5 min/
10 min/30 min/60 min/
1 NM/3 NM/5 NM/10 NM/
0.1 NM/0.2 NM/0.3 NM/
0.5 NM
[Time Label] check box
Check it to enable the time label interval
display.
Enable: Check.
Disable: Uncheck.
[Plot Interval] combo box
(Time Label)
When the time label interval display is
enabled, select a time label interval.
1/3/5/10/30/60 min
[File Load/Save]
shortcut
Opens the [File Load/Save] tab of the [File
Manager] dialogue.
The use state can be confirmed on the [File
Manager] dialogue.
—
