JRC JMR-5400 Series User Manual

6-7 Section 6 Settings
5
6
[Plot] tab (temperature track)
The following table lists the settings when [Temperature] is selected for [Track type] on the [Plot] tab.
Setting item
Description
Setting value
[Track type] combo
box
Select a type of own track.
Temperature: Selectable if the optional plotter
and thermometer are installed.
The depth value is displayed next to the track.
For the case when [Standard] is selected, see
the ‘[Plot] tab (normal track)’ section.
For the case when [Depth] is selected, see the
‘[Plot] tab (depth track)’ section.
Standard / Depth /
Temperature
Temperature field 1
Enter the own track grey/blue boundary
(minimum temperature) value.
−5.0 to [Temperature field
2]
−
1
°
C
Temperature field 2
Enter the own track blue/cyan boundary
(minimum temperature) value.
[Temperature field 1] + 1
to [Temperature field 3]
−
1
°
C
Temperature field 3
Enter the own track cyan/green boundary
(minimum temperature) value.
[Temperature field 2] + 1
to [Temperature field 4]
−
1
°
C
Temperature field 4
Enter the own track green/yellow boundary
(minimum temperature) value.
[Temperature field 3] + 1
to [Temperature field 5]
−
1
°
C
Temperature field 5
Enter the own track yellow/orange boundary
(minimum temperature) value.
[Temperature field 4] + 1
to [Temperature field 6]
−
1
°
C
Temperature field 6
Enter the own track orange/dark red boundary
(minimum temperature) value.
[Temperature field 5] + 1
to 99.9
°
C
[Plot Interval] combo
box
Select a plot interval.
Off/3 s/5 s/10 s/30 s/
1 min/3 min/5 min/
10 min/30 min/60 min/
1 NM/3 NM/5 NM/10 NM/
0.1 NM/0.2 NM/0.3 NM/
0.5 NM
[File Load/Save]
shortcut
Opens the [File Load/Save] tab of the [File
Manager] dialogue.
—
Memo
If a temperature error occurs due to sensor failure, the water temperature value cannot be
displayed on the track.
