3.12.3 File Polling by Using S&F Message Transfer
Land user can access to the MES’s file on IME/DTE’s memory by S&F message transfer. When the
following text is included in the received message, JUE-87 checks the land ID, then transmit the contents
of file or its list to the land user in the text if the user’s number is registered.
Command for position polling
/FILEXXX...XXX/XXX:XXX.....XXX/X..X/
Network type [TELEX, PSDN or Vxx (for PSTN)]
Subscriber’s number (up to 11-digit)
Destination code (3-digit)
File name (8-digit, and extension 3-digit)
Port number of DTE connected (1-digit)
0: Data port main
2: Data port #2 (Option)
Example of position polling
MES receives the following message:
/FILE0QBF.TLX/072:02822351/TELEX/
NNNN
Then, MES transmits the following message to the land user, destination code: 072, subscriber’s
number: 02822351 via Telex:
FILE 0:QBF.TLX
THE QUICK BROWN FOX JUMPS OVER THE LAZY DOG.
