3.16.5 EPADR
3.16.5.1 Confirmation of EPADR Assignment
EPADR Assignment can be confirmed by following procedure.
Step Operation IME/DTE response
1
• Hold down Alt key and press U
key on Main menu.
• "Set up" window is displayed.
2
• Move the cursor to "EPADR
informAtion" and press Enter
key.
• "EPADR Information" window is displayed.
3
• Move the cursor to "EPADR
Assignment" and press Enter key.
• "EPADR Assignment" window is displayed.
4
• Move the cursor to "EPADR
Assignment #1" and press Enter
key.
• "EPADR Assignment #1" window (Fig.3.16.5.1) is
displayed.
5
• Press F9 key.
• Each time F9 key is pressed, other assignments
("EPADR Assignment #1, #2, #3 or #4" window) is
displayed.
Date & time
confiG
log-Out initiation
log-In initiation
Performance test initiation
Scheduled transmission
Land id registration for polling
dnid seleCtion
peripheral Function
password
EPADR informAtion
Set u
p
F10:Previous
EPADR Assignment
EPADR Tx Data
F10:Previous
EPADR Information
EPADR Assignment #1
EPADR Assignment #2
EPADR Assignment #3
EPADR Assi
g
nment #4
F10:Previous
EPADR Assignment
