2-24
2.4.7 Coaxial
Cable
(CFQ-5922A)
Connecting EME and
Antenna Cable.
Max.22mm
Max.8mm
Minimum bending radius: 46mm
T
ype Length
Standard: CFQ-5922A3
30
ｍ
(
±
10cm)
Option: CFQ-5922A4
40
ｍ
(
±
10cm)
Option: CFQ-5922A5
50
ｍ
(
±
10cm)
Fig.2.4.7 Coaxial
Cable
53
55
