JRC jue-87 User Manual

5-5
5
5.2.3 External Buzzer (NCE-5547)
Table 5.2.3a Principal Specification of External Buzzer
Specification
Contents
Interface Binary signal (0V, OPEN)
Power Supply DC +12V (+11.4V to +12.6V)
Dimensions
80 mm (W) × 38 mm (D) × 138 mm (H)
Weight 0.2 kg
Table 5.2.3b The sound status of External Buzzer LED
Communication
Mode or Priority
Sound
High Priority Inmarsat-C MESs
Low Priority
High Priority EGC Receivers
Low Priority
*1) Sound stops when the ‘RESET’ button on the panel of EXT BUZ is pressed.
*2) 2.2 kHz and 1.3 kHz tones sounds alternately.
*3) Sounding time can be selected by the IME command.
