3-110
3.16.3 Confirmation of DNID
DNID can be confirmed by following procedure.
Step Operation IME/DTE response
1
• Hold down Alt key and press U
key on Main menu.
• "Set up" window is displayed.
2
• Move the cursor to "dnid
seleCtion" and press Enter key.
• "DNID selection" window is displayed and
downloaded DNID can be confirmed.
• Confirm that "Enable" is selected to each column.
• DNID on the left of ID number is for EPADR.
Date & time
confiG
log-Out initiation
log-In initiation
Performance test initiation
Scheduled transmission
Land id registration for polling
dnid seleCtion
peripheral Function
password
EPADR informAtion
Set u
F10:Previous
Name DNID(*:for EPADR) LES MEM
ABC 00001 003 001 : Enable
ABC 00001 103 001 : Enable
ABC 00001 203 001 : Enable
ABC 00001 303 001 : Enable
CDE 00002 012 002 : Disable
ABCDEFGHIJKLMNOPQRSTUVWXY *12345 003 100 : Enable
↑↓ contd.(total : 6)
F1:Program information F2:EPADR information F5:Print out F10:Previous
DNID selection
