3.16.4 Confirmation of Polling Program
Polling Program can be confirmed by following procedure.
Step Operation IME/DTE response
1
• Hold down Alt key and press U
key on Main menu.
• "Set up" window is displayed.
2
• Move the cursor to "dnid
seleCtion" and press Enter key.
• "DNID Selection" window is displayed.
3
• Press F1 key at "DNID Selection
window"
• "Polling program information" window is displayed
and downloaded Polling Program can be confirmed.
• Confirm that the status of the Polling Program (STS)
is set to Active (Act).
Fig.3.16.4 “Polling program information” Window
<Explanation of displayed items>
OR: Ocean Region (AOW, AOE, POR, IOR)
LES: Land Earth Station
DNID: Data Network ID
MEM: Member Number
STF: Starting Transmission Frame
ITVL: Transmission Interval Frame
STS: Status (Act: Active, Inact: Inactive)
PKT: Number of transmitted Packet
DATE: Program activated date
* Time (UTC) = Frame x 8.64 sec./1 frame
<Explanation of displayed screen>
In above case, the program activates only in AOW (AOR-W) Ocean Region and executes the Data
reporting (2 packets are sent in each time) at 2500 frames (6 hours) intervals from 1250th frame
(3:00(UTC)) at 2008/8/25.
Program 2 does not activate because its status is [Inact](Inactive).
OR LES DNID MEM STF ITVL STS PKT DATE
AOW 003 12345 123 1250 2500 Act 2 2008/08/25
POR 203 13503 002 1280 1000 Inact
(total : 2)
F5:Print out F10:Previous
