■ Removing a Fan Tray from an EX-series Switch on page 112
■ Installing an Uplink Module in an EX-series Switch on page 101
■ Removing an Uplink Module from an EX-series Switch on page 102
■ Installing an SFP or XFP Transceiver in an EX-series Switch on page 104
■ Removing an SFP or XFP Transceiver from an EX-series Switch on page 106
Installing and Removing EX-series Switch Hardware Components
The EX-series switch chassis is a rigid sheet-metal structure that houses the other
hardware components. The field-replaceable units (FRUs) in EX-series switches are:
■ Power supply
■ Fan tray
■ Uplink module
■ SFP transceiver
■ XFP transceiver
The power supply, fan tray, SFP transceiver, and XFP transceiver in EX-series switches
are hot-removable and hot-insertable FRUs: you can remove and replace them while
the switch is functioning without turning off power to the switch or disrupting switch
functions. The uplink module is not hot-removable and hot-insertable: you must turn
off power to the switch before removing or installing it.
To install a power supply in an EX-series switch, follow instructions in “Installing a
Power Supply in an EX-series Switch” on page 107. To remove a power supply from
an EX-series switch, follow instructions in “Removing a Power Supply from an
EX-series Switch” on page 108.
To install a fan tray in an EX-series switch, follow instructions in “Installing a Fan
Tray in an EX-series Switch” on page 110. To remove a fan tray from an EX-series
switch, follow instructions in “Removing a Fan Tray from an EX-series
Switch” on page 112.
To install an uplink module in an EX-series switch, follow instructions in “Installing
an Uplink Module in an EX-series Switch” on page 101. To remove an uplink module
from an EX-series switch, follow instructions in “Removing an Uplink Module from
an EX-series Switch” on page 102.
To install an SFP or XFP transceiver in an EX-series switch, follow instructions in
“Installing an SFP or XFP Transceiver in an EX-series Switch” on page 104. To remove
an SFP or XFP transceiver from an EX-series switch, follow instructions in “Removing
an SFP or XFP Transceiver from an EX-series Switch” on page 106.
Related Topics ■ Cooling System in an EX 3200 Switch on page 30
■ Cooling System in an EX 4200 Switch on page 32
■ Power Supply in EX 3200 and EX 4200 Switches on page 27
■ EX 3200 Switch—Front-Panel Description on page 9
100 ■ Installing and Removing EX-series Switch Hardware Components
Complete Hardware Guide for EX 3200 and EX 4200 Switches
