Juniper EX Series Complete Hardware Guide

Related Topics ■ Uplink Modules in an EX 3200 or EX 4200 Switch on page 16
■ EX-series Switch—Network Port LEDs on page 15
■ EX 3200 Switch—Front-Panel Description on page 9
■ EX 4200 Switch—Front-Panel Description on page 11
Optical Interface Support—EX 3200 and EX 4200 Switches
Optional uplink modules for EX 3200 and EX 4200 switches support either SFP or
XFP transceivers. This topic describes the optical interfaces supported for those
transceivers. It also lists the copper interface supported for the SFP transceivers.
Table 12 on page 21 describes the optical interface support over single-mode
fiber-optic (SMF) and multimode fiber-optic (MMF) cables for SFP transceivers in
EX 3200 and EX 4200 switches.
Table 12: Optical Interface Support for SFP Transceivers in EX 3200 and EX 4200 Switches
SpecificationsTransceiver
EX-SFP-1GE-SXModel number1000Base-SX Gigabit Ethernet optics
■
550 m (1804.46 ft) on
50 microns MMF cable (minimum
modal bandwidth: 500 MHz-Km)
■
500 m (1640.42 ft) on
50 microns MMF cable (minimum
modal bandwidth: 400 MHz-Km)
■
275 m (902.23 ft) on
62.5 microns MMF cable (minimum
modal bandwidth: 200 MHz-Km)
■
220 m (721.78 ft) on
62.5 microns MMF cable (minimum
modal bandwidth: 160 MHz-Km)
Maximum distance
850 nmTransmitter wavelength
–9.5 dBm through –3 dBmAverage launch power
–21 dBm through –20 dBmReceiver sensitivity
LCConnector type
Optical Interface Support—EX 3200 and EX 4200 Switches ■ 21
Chapter 1: Switch Overview

Juniper EX Series Specifications

General

Series	EX Series
Category	Switch
Layer	Layer 2/3
Operating System	Junos OS
Managed	Yes
ACLs	Yes
Port Density	Varies by model
Power over Ethernet (PoE)	Available on some models
Virtual Chassis	Supported on some models
Form Factor	Fixed configuration, Modular
Switching Capacity	Varies by model
Forwarding Rate	Varies by model
Power Supply	Varies by model (AC or DC, redundant options available)
Management	CLI, Web UI, SNMP
Redundancy	Power supply, fan, Virtual Chassis
Latency	Varies by model
Jumbo Frames	Supported
VLAN Support	Yes
MAC Address Table Size	Varies by model
QoS	Yes
Energy Efficiency	EEE (802.3az)
Dimensions	Varies by model
Weight	Varies by model
Operating Temperature	0° to 45° C
Storage Temperature	-40° to 70° C
Humidity	5% to 90% non-condensing
MTBF	Varies by model
Warranty	Limited Lifetime
