Related Topics Mounting an EX-series Switch on page 65
Installing and Connecting an EX-series Switch on page 61
Connecting and Configuring the EX-series Switch (CLI Procedure) on page 91
Connecting and Configuring the EX-series Switch (J-Web Procedure) on page 92
Installing the Switch
Attaching Mounting Brackets to an EX-series Switch on page 64
Mounting an EX-series Switch on page 65
Mounting an EX-series Switch on a Desk or Other Level Surface on page 66
Mounting an EX-series Switch on a Rack or Cabinet on page 67
Mounting an EX 3200 or EX 4200 Switch on a Wall on page 69
Virtual Chassis Cabling Configuration Examples on page 72
Adding a New Switch to an Existing Virtual Chassis Configuration (CLI
Procedure) on page 75
Connecting Earth Ground to an EX-series Switch on page 78
Connecting AC Power to an EX 3200 or EX 4200 Switch on page 79
Connecting DC Power to an EX 3200 or EX 4200 Switch on page 81
Connecting an EX-series Switch to a Network for Out-of-Band
Management on page 85
Connecting an EX-series Switch to a Management Console on page 86
Connecting a Virtual Chassis Cable to an EX 4200 Switch on page 88
Attaching Mounting Brackets to an EX-series Switch
If you are installing a switch in a rack or cabinet, you must attach mounting brackets
to the switch.
An EX-series switch is shipped with one pair of mounting brackets. The holes in the
mounting brackets are spaced at 1 U (1.75 in. or 4.445 cm), so the switch can be
mounted in any rack that provides holes spaced at that distance.
The outer edges of the mounting brackets extend the width of an EX-series switch
chassis to 19 in. (48.2 cm), and the front of the chassis extends approximately 0.5 in.
(1.27 cm) beyond the mounting brackets. The spacing of rails and adjacent racks
must also allow for the clearances around the switch and rack (see Clearance
Requirements for Airflow and Hardware Maintenance on page 52).
Ensure you have a Phillips (+) screwdriver, number 2 available to install mounting
brackets on an EX-series switch chassis.
To attach each mounting bracket to an EX-series switch (see Figure 29 on page 65):
64 Installing the Switch
Complete Hardware Guide for EX 3200 and EX 4200 Switches
