Table 22: Uplink Modules Connector Pinout Information (continued)

Pin NamePin Number

XAUI0_TX3PE5

XAUI1_TX0NE6

XAUI1_TX1PE7

XAUI1_TX2NE8

XAUI1_TX3PE9

STX28NE10

STX27PE11

STX26NE12

STX25PE13

SGMIITXNE14

Uplink_Hotswap_LEDE15

Uplink_Spare_IntrE16

Uplink_Status_LED1E17

Uplink_P27_LED0E18

POWER (12V)E19

POWER (12V)E20

GNDF1

XAUI0_TX0PF2

GNDF3

XAUI0_TX2PF4

GNDF5

XAUI1_TX0PF6

GNDF7

XAUI_TX2PF8

GNDF9

STX28PF10

GNDF11

Uplink Modules Connector Pinout Information ■ 39

Chapter 1: Switch Overview
