Displaying Text and Markers
9-33
Measuring Dimensions and Area
Displaying Text and Markers
Text comments and markers can be displayed on the observation window. When an image is recorded (saved) with the
comment display turned on, the image is saved with the comment. Comments can be [Normal Comments], which are erased
when the power is turned OFF, or [Residual Comments] which are saved even if the power is turned OFF.
List of normal comments
List of residual comments
Hide
Hides all comments.
Delete All
Deletes all comments.
When an image file is saved with comments, the text or comments cannot be edited.
List of Comments
The total maximum number of normal comments
that can be registered is 999.
Marker type How the marker is drawn Displayed
Comments Displays the comment in the
location specified on the
screen.
Comment
Circle Draws a circle centered at the
clicked point.
[Picture]
Rectangle Draws a rectangle with one of
its corners on the clicked
point.
[Picture]
Ellipse Draws an ellipse that starts at
the clicked point.
[Picture]
Arrow Draws a line that originates at
the clicked point.The arrow
appears at the origin.
[Picture]
Arrow/Text Draws a line that originates at
the clicked point.The arrow
appears at the origin, and the
comment appears at the end
point.
[Picture]
Delete Deletes the comment
specified using the mouse.
[Residual Comments]
cannotbe deleted.
-
Delete All Deletes all normal comments.
[Residual Comments]
cannotbe deleted.
-
Line Format Color and line width for
drawing circles, rectangles,
etc., can be set.
-
Comment
type
Contents Display format
Comment Displays the applicable
text.
Date Displays the date. YYYY/MM/DD
YY/MM/DD
MM/DD/YYYY
MM/DD/YY
DD/MM/YYYY
DD/MM/YY
Time Displays the current time
updated in real time.
hh:mm:ss
Lens Name Displays the lens type and
power.
Lens [type]: x
[power]
Inclination
angle
Displays the inclination
angle of the stage.
Inclination
angle: [value]
degree
