- Digital Microscope VHX-5000 User’s Manual -
Installation/Connection
2-2
Installation/Connection
2
Installation/Connection
This explanation is based on the VHX-5000/VHX-5100 Digital Microscope used with the ultra-small compact high-
performance zoom lens VH-Z20T and the free-angle observation base unit VHX-S550.
System Configuration and Connection Flow
AC
power supply
Connect as needed.
Foot switch
LAN connection
(3)
(4)
(5)
Camera unit
Controller
connecting cable
Lens/ratio automatic
recognition
(TRIPLE'R) cable
(2)
Fiber-optic cable
(1) Installation
(Page 2-3)
(2) Camera unit
connections
(Page 2-3)
(3) Mouse, keyboard,
console connections
(Page 2-5)
(4) AC power supply
connections
(Page 2-5)
(5) Lens and stage
connections
(Page 2-6 to 8)
