Precautions on Regulations and Standards
6
- Digital Microscope VHX-5000 User’s Manual -
Capture high resolution images of features
The HD Image function allows the user to capture high
resolution images employing up to 54 million pixels of data.
Feathers of a Paradise bird (150x)
For details, refer to "Wide-view" (Page 5-9).
Expanded viewing area image capture
The Stitch Image function allows the user to capture wide
area images without sacrificing resolution.
Wire bonding (1000x)
For details, refer to "Manual Image Stitching" (Page 11-8).
Comparative analysis directly on the
system
The Split Screen function allows the user to visually
compare two objects side by side directly on the system.
Switch (20x)
For details, refer to "Split Screen" (Page 8-2).
Measure critical features quickly
The Measurement function allows the user to measure
observed features instantly.
Crystal grains (20x)
For details, refer to "Overview and Type of Measurements" (Page
9-2).
Eliminate vibration
The S.C.F. function allows for clear real time (video)
observation by eliminating vibration.
IC pattern (3000x)
For details, refer to "Reducing the Effects of Vibration (Shake
Correction Mode)" (Page 7-7).
Capture sharp images
The Vivid & Sharp Image function brightens and sharpens
for the image for improved observation.
Solar battery cell (500x)
For details, refer to "Enhance Contours in Vivid Color (Sharpening
Image Mode)" (Page 7-7).
Advanced Analysis Functions
