4-14 Keysight B2961A/B2962A User’s Guide, Edition 3
Front Panel Reference
Display and Assist Keys
Rise Time: Rise time of arbitrary waveform.
Peak Time: Peak time of arbitrary waveform.
Fall Time: Fall time of arbitrary waveform.
End Time: End time of arbitrary waveform.
Count: Number of waveforms to be generated in one device action.
Time: Time of exponential waveform.
T(tau): Time constant of exponential waveform.
Ramp: Ramp (rise) time of ramp waveform.
Amplitude: Amplitude value of sinusoidal waveform.
Offset: Offset value of sinusoidal waveform.
Frequency: Frequency of sinusoidal waveform.
Phase Out: Phase marker output status, ON or OFF, for sinusoidal
waveform. ON enables trigger output at phase marker
position.
Marker: Phase marker value, 0 to 360, in degree.
NOTE To use the trigger output, set trigger output condition by using SCPI commands. See
Keysight B2961A/B2962A SCPI Command Reference.
List Sweep Setup When the field pointer is in the EDIT (green) status on the LIST sweep
Start/Stop/Points field, the following assist keys are available for setting the list
sweep source.
Edit Opens the List Sweep dialog box used to set the list sweep
source.
Load Opens the Load List Sweep Data dialog box used to load a list
sweep data from a USB memory connected to the front panel
USB-A connector.
• List Sweep dialog box
This dialog box provides the following fields for setting the list sweep source.
After the list is completed, press OK to apply the data and close the dialog box.
(data graph) Displays the shape of the list sweep output
(data list) Lists the data index in the left cell and the output value in
the right cell.
