Function Details
Trigger System
Trigger Source
B2961A/B2962A supports the following trigger sources. The trigger source must be
set to the ARM event and the TRIGGER event individually.
• AUTO (automatic internal, AINT): Trigger source best suited for the present
operating mode is automatically selected by the internal algorithms.
• BUS: Remote interface trigger command such as GET, TRIGger, and *TRG
• TIMER (timer, TIMer): Signal internally generated every interval set by the
Period field
• INT1 or INT2 (internal): Signal from the internal bus 1 or 2
• EXT1, EXT2, EXT3, EXT4, EXT5, EXT6, EXT7, EXT8, EXT9, EXT10,
EXT11, EXT12, EXT13, or EXT14 (external): Signal from the DIO pin n,
which is an I/O port of the Digital I/O D-sub connector on the rear panel. n=1 to
14
• LAN: LXI trigger
Device Actions
B2961A/B2962A supports the following device actions. Also see Figure 6-8.
• Transient device action (source output)
Source channel starts source output for applying one output value if the
TRIGGER event was detected and the Source delay time elapsed.
• Acquire device action (measurement)
Measurement channel starts measurement for obtaining one measurement data if
the TRIGGER event was detected and the Measure delay time elapsed.
NOTE To synchronize the channel operation, for the 2-channel models
If channels are set as shown below, the device actions start simultaneously.
• To synchronize source output:
• Trigger source is set to the same mode.
• Delay time is set to the same value.
• Source output ranging mode is set to the fixed mode.
• Source wait time control is set to OFF.
