Keysight B2961A/B2962A User’s Guide, Edition 3 5-15
Front Panel Operations
To Set Source Output
7. For the emulation mode, the emulation table must be set. See “Output R
(Emulation) dialog box” on page 4-31 and set up the emulation table.
To Set Pulse Output
For details on this function, see “Pulse Output” on page 6-7.
1. Press the View key to display the Single view.
2. Press the Show Pulse assist key to display the Pulse parameters. For details on
the parameters, see “Pulse Parameters” on page 4-19.
3. Move the field pointer to the Pulse field.
4. Press the rotary knob to change the pointer status to EDIT.
5. Press the ON assist key. The pointer status is changed to MOVE.
6. Move the field pointer to the pulse parameter setup field (Peak, Delay, or
Width).
7. Press the rotary knob to change the pointer status to EDIT.
8. Enter the pulse peak value (Peak), delay time (Delay), or pulse width (Width).
9. Press the rotary knob or assist key to fix the setting value.
10. Repeat steps 6 to 9 for all parameters.
NOTE Applying the pulse voltage/current
Press the On/Off switch to start the Source value output. The Source value is used as
the pulse base value.
Press the Trigger key to perform the specified pulse output and measurement.
To Set List Sweep Output
For details on this function, see “List Sweep” on page 6-10.
1. Press the View key to display the Single view.
2. If Function parameters are not shown, press the Hide XXXX assist key.
3. Move the field pointer to the Function field.
4. Press the rotary knob to change the pointer status to EDIT.
5. Press the LIST assist key. The pointer status is changed to MOVE.
To Next Page
