5-16 Keysight B2961A/B2962A User’s Guide, Edition 3
Front Panel Operations
To Set Source Output
6. Move the field pointer to the sweep parameter setup field (Start, Stop, or Points).
7. Press the rotary knob to change the pointer status to EDIT.
8. Press the Edit assist key. The List Sweep dialog box opens.
9. Set the list sweep source using the List Sweep dialog box. For details, see “List
Sweep Setup” on page 4-14.
10. To apply the settings, press Apply.
To apply the settings and close the dialog box, press OK.
To cancel the setting change, press the Cancel/Local key.
NOTE Load assist key
If you press the Load assist key instead of the Edit assist key in step 8, the Load List
Sweep Data dialog box opens to allow you to load list sweep data from a USB
memory.
For details, see “List Sweep Setup” on page 4-14.
NOTE Applying the list sweep voltage/current
Press the On/Off switch to start the Source value output.
Press the Trigger key to perform the specified list sweep output and measurement.
To Set Source Output Trigger Parameters
For details on this function, see “Trigger System” on page 6-26 and “Trigger
Parameters” on page 4-20.
1. Press the View key to display the Single view.
2. Press the Show Trigger assist key to display the Trigger parameters.
3. Move the field pointer to the Trigger field.
4. Press the rotary knob to change the pointer status to EDIT.
5. Press the AUTO, SYNC, TIMER, or MANUAL assist key to set the trigger
type. The pointer status is changed to MOVE.
6. Move the field pointer to the trigger parameter setup field (Count, Delay, Period,
or Trigger in the Source column).
7. Press the rotary knob to change the pointer status to EDIT.
To Next Page
