Keysight B2961A/B2962A User’s Guide, Edition 3 4-17
Front Panel Reference
Display and Assist Keys
Delete Deletes the line.
Scroll -100 Moves the pointer to the maximum 100
points above.
Scroll +100 Moves the pointer to the maximum 100
points below.
Source Source function (VOLTS or AMPS)
CH Channel number 1 or 2, only on 2-channel models
Points Number of data points
Max Maximum value
Min Minimum value
Trigger Sets the trigger output ON () or OFF (blank) for each line.
Setting ON enables the trigger output synchronized with the
output of the value set to the center cell.
NOTE To use the trigger output, set trigger output condition by using SCPI commands. See
Keysight B2961A/B2962A SCPI Command Reference.
• Load User Defined Waveform dialog box
This dialog box provides the following fields for loading a waveform data from
a file stored on a USB memory. Highlight a file and press OK to load the data
and close the dialog box.
(data graph) Displays the shape of the waveform data selected by the file
list
(file list) List of the waveform data file
Path Folder into which the waveform data file is saved
Points Number of data points
Max Maximum value
Min Minimum value
The following data can be loaded as the waveform data.
• Comma separated value format, file extension csv
• Carriage return or line feed separated value format, file extension txt
• Space separated value format in a line, file extension prn
