Keysight B2961A/B2962A User’s Guide, Edition 3 6-21
Function Details
Math Expression
Table 6-2 Reserved Variables
Table 6-3 Arithmetic and Unary Operators
Reserved variable
a
a. The numeric suffix [c] is effective for specifying the channel. For exam-
ple, use CURR2 to read the current spot measurement data of the chan-
nel 2.
Description
Scalar Vector
SOUR[c]SOUR[c][] Source output setting data
VOLT[c] VOLT[c][] Voltage measurement data
CURR[c]CURR[c][] Current measurement data
RES[c]RES[c][] Resistance measurement data
TIME[c]TIME[c][] Time (timestamp) data
Priority of task Operator Description
High
:
:
:
:
:
Low
( ) Parentheses
+ and - Unary plus operator and unary minus operator
^ Exponentiation operator
* and / Multiplication operator and division operator
+ and - Additive operator and subtraction operator
