Keysight Technologies B2961A User Manual

2-14 Keysight B2961A/B2962A User’s Guide, Edition 3
Introduction
Power Source
Table 2-4 Limitations for using Channels 1 and 2
Table 2-5 Current Measurement Range
Channel 1 voltage V1 Channel 2 voltage V2
Current limit
a
a. I1: Channel 1 current, I2: Channel 2 current
0 < |V1|  6 V 0 < |V2|  6 V I1 + I2  4 A
6 V < |V2|  21 V I1 + I2  1.6  4 A
6 V < |V1|  21 V 0 < |V2|  6 V I1 + I2  0.625  2.5 A
6 V < |V2|  21 V I1 + I2  2.5 A
Range value Current measurement value Resolution
10 nA 0  |I|  10.6 nA 1 pA
100 nA 0  |I|  106 nA 10 pA
1 A0  |I|  1.06 A 100 pA
10 A0  |I|  10.6 A1 nA
100 A0  |I|  106 A 10 nA
1 mA 0  |I|  1.06 mA 100 nA
10 mA 0  |I|  10.6 mA 1 A
100 mA 0  |I|  106 mA 10 A
1 A 0  |I|  1.06 A 100 A
1.5 A 0  |I|  1.53 A
3 A 0  |I|
 3.06 A 1 mA
10 A
a
a. Available for pulse mode. Not available for DC mode.
0  |I|  10.6 A
