Keysight B2961A/B2962A User’s Guide, Edition 3 3-25
Installation
Connecting a DUT
NOTE Performing high voltage measurement
When the Digital I/O interlock terminal is open, B2961A/B2962A cannot apply
high voltage over 42 V. To perform high voltage measurements, B2961A/B2962A
must be connected to the interlock circuit installed in 16442B.
Prepare the N1294A-011 or 012 interlock cable, and connect it between the
B2961A/B2962A Digital I/O connector and the 16442B Intlk connector.
B2961A/B2962A can apply a high voltage when the test fixture cover is closed.
WARNING Hazardous voltage, instrument maximum output voltage may appear at the
High Force, High Sense, and Guard terminals if the fixture cover is closed.
To prevent electrical shock, do not expose these lines.
Une tension dangereuse, une tension de sortie maximale de l'appareil peut
apparaître aux bornes High Force, High Sense et Guard si le couvercle de
l'équipement est fermé. Afin d’éviter toute décharge électrique, n’exposez pas
ces lignes.
