134 Keysight InfiniiVision 2000 X-Series Oscilloscopes User's Guide
9 Labels
Turning the Entry knob selects a character to enter into the highlighted position
shown in the "New label =" line above the softkeys and in the Spell softkey.
Labels can be up to ten characters in length.
4 Press the Enter softkey to enter the selected character and to go to the next
character position.
5 You may position the highlight on any character in the label name by
successively pressing the Enter softkey.
6 To delete a character from the label, press the Enter softkey until the letter you
want to delete is highlighted, then press the Delete Character softkey.
7 When you are done entering characters for the label, press the Apply New Label
softkey to assign the label to the selected channel.
When you define a new label, it is added to the nonvolatile label list.
Label Assignment
Auto-Increment
When you assign a label ending in a digit, such as ADDR0 or DATA0, the
oscilloscope automatically increments the digit and displays the modified label in
the "New label" field after you press the Apply New Label softkey. Therefore, you
only need to select a new channel and press the Apply New Label softkey again to
assign the label to the channel. Only the original label is saved in the label list. This
feature makes it easier to assign successive labels to numbered control lines and
data bus lines.
To load a list of labels from a text file you create
It may be convenient to create a list of labels using a text editor, then load the
label list into the oscilloscope. This lets you type on a keyboard rather than edit
the label list using the oscilloscope's controls.
You can create a list of up to 75 labels and load it into the oscilloscope. Labels are
added to the beginning of the list. If more than 75 labels are loaded, only the first
75 are stored.
To load labels from a text file into the oscilloscope:
You can use a connected USB keyboard instead of using the Spell (and other) character
editing softkeys.
