Keysight InfiniiVision 2000 X-Series Oscilloscopes User's Guide 15
Maximum voltage at oscilloscope external trigger input / 175
12 Acquisition Control
Running, Stopping, and Making Single Acquisitions (Run
Control) / 177
Overview of Sampling / 178
Sampling Theory / 179
Aliasing / 179
Oscilloscope Bandwidth and Sample Rate / 179
Oscilloscope Rise Time / 181
Oscilloscope Bandwidth Required / 182
Memory Depth and Sample Rate / 182
Selecting the Acquisition Mode / 183
Normal Acquisition Mode / 184
Peak Detect Acquisition Mode / 184
Averaging Acquisition Mode / 186
High Resolution Acquisition Mode / 188
Acquiring to Segmented Memory / 189
Navigating Segments / 190
Infinite Persistence with Segmented Memory / 191
Segmented Memory Re-Arm Time / 191
Saving Data from Segmented Memory / 191
13 Cursors
To make cursor measurements / 194
Cursor Examples / 197
14 Measurements
To make automatic measurements / 204
Measurements Summary / 206
