Keysight Technologies InfiniiVision 2000 X Series User Manual

47
Keysight InfiniiVision 2000 X-Series Oscilloscopes
User's Guide
2 Horizontal Controls
To adjust the horizontal (time/div) scale / 48
To adjust the horizontal delay (position) / 49
Panning and Zooming Single or Stopped Acquisitions / 50
To change the horizontal time mode (Normal, XY, or Roll) / 50
To display the zoomed time base / 54
To change the horizontal scale knob's coarse/fine adjustment setting / 55
To position the time reference (left, center, right) / 56
Searching for Events / 56
Navigating the Time Base / 57
The horizontal controls include:
• The horizontal scale and position knobs.
•The [Horiz] key for accessing the Horizontal Menu.
• The zoom key for quickly enabling/disabling the split-screen zoom display.
•The [Search] key for finding events on analog channels or in serial decode.
•The [Navigate] keys for navigating time, search events, or segmented memory
acquisitions.
The following figure shows the Horizontal Menu which appears after pressing the
[Horiz] key.
