Keysight InfiniiVision 2000 X-Series Oscilloscopes User's Guide 7
For reference information, see: • Chapter 22, “Reference,” starting on page 309
When using licensed serial bus
triggering and decode features, see:
• Chapter 23, “CAN/LIN Triggering and Serial Decode,”
starting on page 327
• Chapter 24, “I2C/SPI Triggering and Serial Decode,”
starting on page 343
• Chapter 25, “UART/RS232 Triggering and Serial
Decode,” starting on page 361
Abbreviated instructions for pressing a series of keys and softkeys
Instructions for pressing a series of keys are written in an abbreviated manner. Instructions for
pressing [Key1], then pressing Softkey2, then pressing Softkey3 are abbreviated as follows:
Press [Key1]> Softkey2 > Softkey3.
The keys may be a front panel [Key] or a Softkey. Softkeys are the six keys located directly
below the oscilloscope display.
