General Programming 6
Keysight M8195A Revision 2 – Arbitrary Waveform Generator User’s Guide 239
6.21 :TRACe Subsystem
Use the :TRACe subsystem to control the arbitrary waveforms and their respective
parameters:
Create waveform segments of arbitrary size with optional initialization.
Download waveform data with or without marker data into the segments.
Delete one or all waveform segments from the waveform memory.
6.21.1 Waveform Data Format
In the data formats shown below the fields have the following meanings:
DB7…DB0 - Sample as signed 8-bit value, valid range is -128 to +127.
M1, M2 – Marker bits for Marker 1 and 2 to be output on channel 3 and 4,
respectively.
Table 44: Sample data format without markers
Table 45: Sample data format with markers
