Keysight M8195A - Sequence Mode

Sequencing 3
Keysight M8195A Revision 2 – Arbitrary Waveform Generator User’s Guide 127
3.8.2 Sequence Mode
In Sequence Mode, one or multiple segments are played.
a b c d
AUTO CONDITIONAL REPEATED SINGLE
SEQUENCE
Segment
2
c
2
2
2
Figure 41: Sequence Mode
3.8.2.1 Self Armed
Trigger Mode
Continuous
After programming, the sequence is started automatically and played infinitely.
The following segment advancement modes are available:
 Auto
 Conditional (Advancement Event)
 Repeated (Advancement Event)
 Single (Advancement Event)
