SECTION 4 MODBUS PROTOCOL
Address Parameter Description R/W Unit Data Type
Phase 1
28 L1 V Phase1 voltage RO V 32 bit flo t
30 L1 I Phase1 current RO A 32 bit flo t
32 L1 P Phase1 active power RO W 32 bit flo t
34 L1 Q Phase1 reactive power RO VAr 32 bit flo t
36 L1 S Phase1 apparent power RO VA 32 bit flo t
38 L1 CosØ Phase1 CosØ RO - 32 bit flo t
40 L1 PF Phase1 power factor RO - 32 bit flo t
42 L1 F Phase1 frequency RO Hz 32 bit flo t
44 L1 THDV Phase1 total har. distortion of voltage RO % 32 bit flo t
46 L1 THDI Phase1 total har. distortion of current RO % 32 bit flo t
48 L1 V Harmonics1 Phase1 voltage first harmonic RO % 32 bit flo t
50 L1 V Harmonics3 Phase1 voltage third harmonic RO % 32 bit flo t
52 L1 V Harmonics5 Phase1 voltage 5th harmonic RO % 32 bit flo t
54 L1 V Harmonics7 Phase1 voltage 7th harmonic RO % 32 bit flo t
56 L1 V Harmonics9 Phase1 voltage 9th harmonic RO % 32 bit flo t
58 L1 V Harmonics11 Phase1 voltage 11th harmonic RO % 32 bit flo t
60 L1 V Harmonics13 Phase1 voltage 13th harmonic RO % 32 bit flo t
62 L1 V Harmonics15 Phase1 voltage 15th harmonic RO % 32 bit flo t
64 L1 V Harmonics17 Phase1 voltage 17th harmonic RO % 32 bit flo t
66 L1 V Harmonics19 Phase1 voltage 19th harmonic RO % 32 bit flo t
68 L1 V Harmonics21 Phase1 voltage 21th harmonic RO % 32 bit flo t
70 L1 V Harmonics23 Phase1 voltage 23th harmonic RO % 32 bit flo t
72 L1 V Harmonics25 Phase1 voltage 25th harmonic RO % 32 bit flo t
74 L1 V Harmonics27 Phase1 voltage 27th harmonic RO % 32 bit flo t
76 L1 V Harmonics29 Phase1 voltage 29th harmonic RO % 32 bit flo t
78 L1 V Harmonics31 Phase1 voltage 31th harmonic RO % 32 bit flo t
80 L1 V Harmonics33 Phase1 voltage 33th harmonic RO % 32 bit flo t
82 L1 V Harmonics35 Phase1 voltage 35th harmonic RO % 32 bit flo t
84 L1 V Harmonics37 Phase1 voltage 37th harmonic RO % 32 bit flo t
86 L1 V Harmonics39 Phase1 voltage 39th harmonic RO % 32 bit flo t
88 L1 V Harmonics41 Phase1 voltage 41th harmonic RO % 32 bit flo t
90 L1 V Harmonics43 Phase1 voltage 43th harmonic RO % 32 bit flo t
92 L1 V Harmonics45 Phase1 voltage 45th harmonic RO % 32 bit flo t
94 L1 V Harmonics47 Phase1 voltage 47th harmonic RO % 32 bit flo t
96 L1 V Harmonics49 Phase1 voltage 49th harmonic RO % 32 bit flo t
98 L1 V Harmonics51 Phase1 voltage 51th harmonic RO % 32 bit flo t
100 L1 I Harmonics1 Phase1 current first harmonic RO % 32 bit flo t
102 L1 I Harmonics3 Phase1 current third harmonic RO % 32 bit flo t
104 L1 I Harmonics5 Phase1 current 5th harmonic RO % 32 bit flo t
106 L1 I Harmonics7 Phase1 current 7th harmonic RO % 32 bit flo t
108 L1 I Harmonics9 Phase1 current 9th harmonic RO % 32 bit flo t
110 L1 I Harmonics11 Phase1 current 11th harmonic RO % 32 bit flo t
112 L1 I Harmonics13 Phase1 current 13th harmonic RO % 32 bit flo t
114 L1 I Harmonics15 Phase1 current 15th harmonic RO % 32 bit flo t
