SECTION 4 MODBUS PROTOCOL
Address Parameter Description R/W Unit Data Type
116 L1 I Harmonics17 Phase1 current 17th harmonic RO % 32 bit flo t
118 L1 I Harmonics19 Phase1 current 19th harmonic RO % 32 bit flo t
120 L1 I Harmonics21 Phase1 current 21th harmonic RO % 32 bit flo t
122 L1 I Harmonics23 Phase1 current 23th harmonic RO % 32 bit flo t
124 L1 I Harmonics25 Phase1 current 25th harmonic RO % 32 bit flo t
126 L1 I Harmonics27 Phase1 current 27th harmonic RO % 32 bit flo t
128 L1 I Harmonics29 Phase1 current 29th harmonic RO % 32 bit flo t
130 L1 I Harmonics31 Phase1 current 31th harmonic RO % 32 bit flo t
132 L1 I Harmonics33 Phase1 current 33th harmonic RO % 32 bit flo t
134 L1 I Harmonics35 Phase1 current 35th harmonic RO % 32 bit flo t
136 L1 I Harmonics37 Phase1 current 37th harmonic RO % 32 bit flo t
138 L1 I Harmonics39 Phase1 current 39th harmonic RO % 32 bit flo t
140 L1 I Harmonics41 Phase1 current 41th harmonic RO % 32 bit flo t
142 L1 I Harmonics43 Phase1 current 43th harmonic RO % 32 bit flo t
144 L1 I Harmonics45 Phase1 current 45th harmonic RO % 32 bit flo t
146 L1 I Harmonics47 Phase1 current 47th harmonic RO % 32 bit flo t
148 L1 I Harmonics49 Phase1 current 49th harmonic RO % 32 bit flo t
150 L1 I Harmonics51 Phase1 current 51th harmonic RO % 32 bit flo t
Phase 2
152 L2 V Phase2 voltage RO V 32 bit flo t
154 L2 I Phase2 current RO A 32 bit flo t
156 L2 P Phase2 active power RO W 32 bit flo t
158 L2 Q Phase2 reactive power RO VAr 32 bit flo t
160 L2 S Phase2 apparent power RO VA 32 bit flo t
162 L2 CosØ Phase2 CosØ RO - 32 bit flo t
164 L2 PF Phase2 power factor RO - 32 bit flo t
166 L2 F Phase2 frequency RO Hz 32 bit flo t
168 L2 THDV Phase2 total har. distortion of voltage RO % 32 bit flo t
170 L2 THDI Phase2 total har. distortion of current RO % 32 bit flo t
172 L2 V Harmonics1 Phase2 voltage first harmonic RO % 32 bit flo t
174 L2 V Harmonics3 Phase2 voltage third harmonic RO % 32 bit flo t
176 L2 V Harmonics5 Phase2 voltage 5th harmonic RO % 32 bit flo t
178 L2 V Harmonics7 Phase2 voltage 7th harmonic RO % 32 bit flo t
180 L2 V Harmonics9 Phase2 voltage 9th harmonic RO % 32 bit flo t
182 L2 V Harmonics11 Phase2 voltage 11th harmonic RO % 32 bit flo t
184 L2 V Harmonics13 Phase2 voltage 13th harmonic RO % 32 bit flo t
186 L2 V Harmonics15 Phase2 voltage 15th harmonic RO % 32 bit flo t
188 L2 V Harmonics17 Phase2 voltage 17th harmonic RO % 32 bit flo t
190 L2 V Harmonics19 Phase2 voltage 19th harmonic RO % 32 bit flo t
192 L2 V Harmonics21 Phase2 voltage 21th harmonic RO % 32 bit flo t
194 L2 V Harmonics23 Phase2 voltage 23th harmonic RO % 32 bit flo t
196 L2 V Harmonics25 Phase2 voltage 25th harmonic RO % 32 bit flo t
198 L2 V Harmonics27 Phase2 voltage 27th harmonic RO % 32 bit flo t
200 L2 V Harmonics29 Phase2 voltage 29th harmonic RO % 32 bit flo t
202 L2 V Harmonics31 Phase2 voltage 31th harmonic RO % 32 bit flo t
