150
In Disk mode you can press the [F1]–[F4] keys located below
the tab to select the desired page.
Here you can load a selected file or directory into internal
memory.
Use the [F5] (“UP”) key and [F6] (“OPEN”) key to select the
desired file or directory. Then use the Utility “Load selected”
(1.1–1f) to select and load the data.
1.1–1a: Current directory
The directory currently selected for processing is referred to
as the “current directory.”
The LCD screen will show the full path name of the direc-
tory. A slash “/” character is used as the delimiter between
directory levels. To change the current directory, use the [F5]
(“UP”) key and [F6] (“OPEN”) key.
1.1–1b: Directory window
Directory window
File information for the current directory is shown here.
You can select a file or directory in this window.
b1: File index
This displays the file index.
b2: File/icon
The icon indicates the type of file.
For details on icons,
☞p.149.
b3: File name
This is the name of the file (DOS file).
b4: Size
This is the size of the file (in bytes).
b5: Save date and time
This shows the date and time when the file was saved. From
the left, this is shown as day, month, year, hours and min-
utes.
However since this instrument does not contain an internal
calendar or clock, you must use “Set Date/Time” (1.1–3a) to
set the date and time before saving the file.
1.1–1c: Label
This displays the volume label of the floppy disk when load-
ing or saving.
When you insert a floppy disk and press the [DISK] key or a
function key to make this instrument recognize the disk, its
volume label will be displayed. If there is no volume label,
the display will indicate “no label.” If the disk is not format-
ted, the display will indicate “Unformatted.”
1.1–1d: File select
The file/directory selected in the directory window will be
shown in “Index:” The total number of files in the current
directory is shown in “(/).”
■ 1.1–1e: UP, OPEN
Indicates the current directory.
Use the [F5] (“UP”) key and [F6] (“OPEN”) key to select the
current directory.
: Move to the higher directory.
: Move to a lower directory.
■ 1.1–1f: UTILITY
For details on how to select the desired utility function, refer
to “PROG 1.1–1c: UTILITY.”
Hide unknown file
Select “Hide unknown file” in the utility menu and press the
[F8] key. A check mark will appear at the left of “Hide
unknown file.” With this setting, undefined files will not be
displayed in the directory window. However, this is effec-
tive only if the current directory is a DOS directory.
Load selected
This command loads into internal memory the file or direc-
tory that was selected in the “directory window” (1.1–1b).
When you choose “Load Selected” from the Utility menu, a
dialog box will appear. The dialog box will differ depending
on the type of file to be loaded.
DISK PAGE MENU
Load Load the contents of the selected file or directory
into internal memory. (
☞p.150)
Save Save various from internal memory to disk.
(
☞p.153)
Utility Rename, copy, or delete a selected disk or file,
create a new directory, or specify the date and
time. (
☞p.155)
Media Information View information on the floppy disk. (
☞p.157)
1.1–1: Load
1.1–1a
1.1–1b
1.1–1c
1.1–1f1.1–1e1.1–1d
b1 b2 b3 b4 b5
