214
093: Vocoder
This effect applies the character of the right channel signal
(Modulator) to the left channel signal input (Carrier). Sounds
such as rhythm and sound effects are suitable for use as the
modulator, and sounds with rich harmonic structure such as
strings and distortion guitar are suitable for use as the carrier.
c: Formant Shift
By offsetting the Carrier filter, you can adjust the height of the fre-
quency range to which the vocoder effect is applied. The tonal
quality will change significantly.
f: Noise
This parameter enables you to mix white noise with the Carrier.
g: Modulator High Mix
This parameter sets the high-range output level of the right chan-
nel sound (Modulator). If the modulator is a human voice, it will
make the words more clear.
h: V/C, i: W/D
The “V/C” parameter sets the balance between the vocoder
sound and the left channel sound (Carrier). The “W/D” parame-
ter sets the balance between the effect and dry sound.
If you wish to change the intensity of the vocoder effect, select
Wet for “W/D”, and adjust the balance using the “V/C” parame-
ter.
a
Wah Off, On
Switches Wah on/off
☞ Fx:006,
(Source) Off...Tempo
Selects the modulation source that switches the Wah on and off
☞ Fx:006
(Sw) Tggl, Mmnt
Selects the switching mode for the modulation source that switches
the Wah on and off
☞ Fx:006
b
SweepRng (Wah Sweep Range) –10...+10
Sets the range of Wah
☞ Fx:006,
Src (Source) Off...Tempo
Selects the modulation source that controls the Wah
c
Mode (Drive Mode) Overdrive, HyperGain
Switching between overdrive and hyper-gain mode
Drive
Sets the degree of distortion
1...120
☞ Fx:006
d
Pre Low-cut 0...10
Sets the low range cut amount of the distortion input
☞ Fx:006
e
Level (Output Level) 0...50
Sets the output level
☞ Fx:006,
(Source)
Selects the modulation source for the output level
Off...Tempo
(Amount)
Sets the modulation amount of the output level
–50...+50
f
Lo (Low Cutoff) 20...1.00kHz
Sets the center frequency for Low EQ (shelving type)
G (Gain)
Sets the gain of Low EQ
–18...+18dB
g
M1 (Mid1 Cutoff) 300...10.00kHz
Sets the center frequency for Mid/High EQ 1 (peaking type)
Q
Sets the band width of Mid/High EQ 1
0.5...10.0
☞ Fx:006
G (Gain)
Sets the gain of Mid/High EQ 1
–18...+18dB
h
M2 (Mid2 Cutoff) 500...20.00kHz
Sets the center frequency for Mid/High EQ 2 (peaking type)
Q
Sets the band width of Mid/High EQ 2
0.5...10.0
☞ Fx:006
G (Gain)
Sets the gain of Mid/High EQ 2
–18...+18dB
i
Direct Mix
Amount of the dry sound mixed to the distortion
0...50
SpSim (Speaker Simulation)
Speaker simulation on/off
Off, On
j
W/D (Wet/Dly) Dry, 1:99...99:1, Wet
Sets the balance between the effect and dry sounds
(Source) Off...Tempo
Selects the modulation source of the effect balance
(Amount)
Sets the modulation amount of the effect balance
–100...+100
Left
Right
Wet / Dry
Wet / Dry
Wet: Stereo In - Mono Out / Dry: Stereo In - Stereo Out
Band Pass Filter
Envelope
+
Modulator
Carrier
Lch (Carrier)
Trim
Rch (Modulator)
Trim
Modulator High Mix
Vocoder /
Carrier
Noise
Generator
Noise Level
+
a
L (Carrier) Trim
Sets the input level of left channel (Carrier)
0...100
b
R (Modulator) Trim
Sets the input level of right channel (Modulator)
0...100
c
Formant Shift –2...+2
Sets the height of the frequency for the vocoder effect
☞
d
Response 0...100
Sets the speed of the response to the modulator input
e
LoGain (Low Gain)
Sets the low-range output level of the vocoder
–12...+12
HiGain (High Gain)
Sets the high-range output level of the vocoder
–12...+12
f
Noise (Noise Level)
Sets the noise mix level to the Carrier
0...100
☞,
(Source) Off...Tempo
Selects the modulation source for the noise mix level
(Amount) –100...+100
Sets the modulation amount for the noise mix level
g
Modulator High Mix
Sets the high-range output level of the modulator
0...100
☞
h
V/C (Vocoder/Carrier) Carrier, 1:99...99:1, Vocoder
Sets the balance between the vocoder output and the Carrier
☞,
(Source) Off...Tempo
Selects the modulation source for the balance between the vocoder
output and the carrier
(Amount) –100...+100
Sets the modulation amount of the balance between the vocoder out-
put and the carrier
i
W/D (Wet/Dly) Dry, 1:99...99:1, Wet
Sets the balance between the effect and dry sounds
☞,
(Source) Off...Tempo
Selects the modulation source of the effect balance
(Amount)
Sets the modulation amount of the effect balance
–100...+100
