Effect
193
044: St/Cross Dly
(Stereo/Cross Delay)
This is a stereo delay, and can by used as a cross-feedback
delay effect in which the delay sounds cross over between the
left and right by changing the feedback routing.
045: St.MltTap Dly
(Stereo Multitap Delay)
The left and right Multitap Delays have two taps respectively.
Changing the routing of feedback and tap output allows you
to create various patterns of complex effect sounds.
a: Mode
You can change how the left and right delay signals are panned by
modifying the routing of the left and right delay as shown in the
figure above. You need to input different sounds to each channel
in order for this parameter to be effective.
d: Tap1 Level
This parameter sets the output level of Tap1. Setting a different
level from Tap2 will add a unique touch to a monotonous delay
and feedback.
a
Stereo/Cross Stereo, Cross
Switches between stereo delay and cross-feedback delay
b
L Delay (L Delay Time)
Sets the delay time for the left channel
0.0...680.0ms
c
R Delay (R Delay Time)
Sets the delay time for the right channel
0.0...680.0ms
d
L Fb (L Feedback)
Sets the feedback amount for the left channel
–100...+100
(Source) Off...Tempo
Selects the modulation source of feedback amount
(Amount L) –100...+100
Sets the modulation amount of the left channel feedback
e
R Fb (R Feedback)
Sets the feedback amount for the right channel
–100...+100
(Amount R) –100...+100
Sets the modulation amount of the right channel feedback
f
HiDamp (High Damp)
Sets the damping amount in the high range
0...100%
☞ Fx:043
g
LoDamp (Low Damp)
Sets the damping amount in the low range
0...100%
☞ Fx:043
h
InLvl Mod (Input Level Dmod [%]) –100...+100
Sets the modulation amount of the input level
☞ Fx:037,
Src (Source)
Selects the modulation source for the input level
Off...Tempo
☞ Fx:037
i
Spread –50...+50
Sets the width of the stereo image of the effect sound
☞ Fx:043
j
W/D (Wet/Dly) Dry, 1:99...99:1, Wet
Sets the balance between the effect and dry sounds
(Source) Off...Tempo
Selects the modulation source of the effect balance
(Amount)
Sets the modulation amount of the effect balance
–100...+100
Delay
Delay
Stereo/Cross
Left
Right
Feedback
Wet / Dry
Wet / Dry
Stereo In - Stereo Out
Input Level D-mod
Input Level D-mod
High Damp Low Damp
High Damp
Low Damp
Spread
Stereo/Cross
a
Mode Normal, Cross Feedback, Cross Pan1, Cross Pan2
Switches the left and right delay routing
☞
b
Tap1 Time
Sets the Tap1 delay time
0.0...680.0ms
c
Tap2 Time
Sets the Tap2 delay time
0.0...680.0ms
d
Tap1 Level
Sets the Tap1 output level
0...100
☞
e
Fb(T2) (Tap2 Feedback)
Sets the Tap2 feedback amount
–100...+100
(Source) Off...Tempo
Selects the modulation source of the Tap2 feedback amount
(Amount) –100...+100
Sets the modulation amount of the Tap2 feedback amount
f
HiDamp (High Damp)
Sets the damping amount in the high range
0...100%
☞ Fx:043
LoDamp (Low Damp)
Sets the damping amount in the low range
0...100%
☞ Fx:043
g
InLvl Mod (Input Level Dmod [%]) –100...+100
Sets the modulation amount of the input level
☞ Fx:037,
Src (Source)
Selects the modulation source for the input level
Off...Tempo
☞ Fx:037
h
Spread –100...+100
Sets the width of the stereo image of the effect sound
☞ Fx:043,
(Source) Off...Tempo
Selects the modulation source of the effect sound’s stereo image
width
(Amount) –100...+100
Sets the modulation amount of the effect sound’s stereo image width
i
W/D (Wet/Dly) Dry, 1:99...99:1, Wet
Sets the balance between the effect and dry sounds
(Source) Off...Tempo
Selects the modulation source of the effect balance
(Amount)
Sets the modulation amount of the effect balance
–100...+100
Left
Right
Feedback
Spread
Wet / Dry
Wet / Dry
Stereo In - Stereo Out
Input Level D-mod
Input Level D-mod
High Damp
Low Damp
High Damp
Low Damp
Delay
Delay
Feedback
Tap1 Level
Mode
Mode
(1)
(2)
(1)
(2)
Tap1=(1)
Tap2=(2)
Mode: Normal Mode: Cross Feedback Mode: Cross Pan1
Mode: Cross Pan2
