Korg Karma User Manual

Effect
203
067: Comp–Cho/Fl
(Compressor – Chorus/Flanger)
This effect combines a mono-type compressor and a chorus/
flanger. You can change the order of the effect connection.
g: Out, h: [Routing]
When Wet Inv is selected, the right channel phase of the chorus/
flanger effect sound is inverted. This creates pseudo-stereo effects
and adds spread.
However, if a mono-input type effect is connected after this effect,
the left and right sounds may cancel each other, eliminating the
chorus/flanger effects.
When “[Routing]” is set to CH/FL→CMP, “Out” will be set to
Normal.
068: Comp–Phaser
(Compressor – Phaser)
This effect combines a mono-type compressor and a phaser.
You can change the order of the effect connection.
e
B1 (Band1 Cutoff)
Sets the center frequency of Band 1
20...1.00kHz
Q
Sets the bandwidth of Band 1
0.5...10.0
☞ Fx:006
G (Gain)
Sets the gain of Band 1
–18...+18dB
f
B2 (Band2 Cutoff)
Sets the center frequency of Band 2
50...5.00kHz
Q
Sets the bandwidth of Band 2
0.5...10.0
☞ Fx:006
G (Gain)
Sets the gain of Band 2
–18...+18dB
g
C/F W/D (Cho/Flng Wet/Dry)
Sets the center frequency for Band 3
300...10.00kHz
Q
Sets the bandwidth of Band 3
0.5...10.0
☞ Fx:006
G (Gain)
Sets the gain of Band 3
–18...+18dB
h
B4 (Band4 Cutoff)
Sets the center frequency for Band 4
500...20.00kHz
Q
Sets the bandwidth of Band 4
0.5...10.0
☞ Fx:006
G (Gain)
Sets the gain of Band 4
–18...+18dB
i
W/D (Wet/Dly) Dry, 1:99...99:1, Wet
Sets the balance between the effect and dry sounds
(Source) Off...Tempo
Selects the modulation source of the effect balance
(Amount)
Sets the modulation amount of the effect balance
–100...+100
a
[CMP] Sensitivity
Sets the sensitivity
1...100
☞ Fx:002
b
Attack
Sets the attack level
1...100
☞ Fx:002
Level (Output Level)
Sets the compressor output level
0...100
☞ Fx:002
c
Pre EQ Trim
Sets the EQ input level
0...100
d
LoEQ (Pre Low EQ Gain)
Sets the gain of Low EQ
–15...+15dB
HiEQ (Pre High EQ Gain)
Sets the gain of High EQ
–15...+15dB
e
[CH/FL] LFO (LFO Waveform)
Selects the LFO waveform of the chorus/flanger
Tri, Sine
F (LFO Frequency)
Sets the LFO speed
0.02...20.00Hz
f
Dly (Delay Time)
Sets the delay time
0.0...50.0ms
Dep (Depth)
Sets the depth of LFO modulation
0...100
Fb (Feedback)
Sets the feedback amount
–100...+100
☞ Fx:020
Left
Right
Wet / Dry
Wet / Dry
Wet: Mono In - Stereo Out / Dry: Stereo In - Stereo Out
+
Routing
Compressor
Chorus/Flanger
Chorus/Flanger
Feedback
LFO: Tri / Sine
Cho/Flng Wet / Dry
Normal
Wet Invert
Output Mode
–
+
LEQ HEQ
EQ Trim
Comp
Output Level
Envelope - Control
g
[F] Cho/Flng W/D –Wet...–2:98, Dry, 2:98...Wet
Sets the effect balance of the chorus/flanger
☞ Fx:010, 020
Out (Output Mode) Normal, Wet Inv
Selects the output mode for the chorus/flanger
☞
h
[Routing] CMP → CF/FL, CH/FL → CMP
Switches the order of the compressor and chorus/flanger connection
☞
i
W/D (Wet/Dly) Dry, 1:99...99:1, Wet
Sets the balance between the effect and dry sounds
(Source) Off...Tempo
Selects the modulation source of the effect balance
(Amount)
Sets the modulation amount of the effect balance
–100...+100
a
[CMP] Sensitivity
Sets the sensitivity
1...100
☞ Fx:002
b
Attack
Sets the attack level
1...100
☞ Fx:002
Level (Output Level)
Sets the compressor output level
0...100
☞ Fx:002
c
Pre EQ Trim
Sets the EQ input level
0...100
d
LoEQ (Pre Low EQ Gain)
Sets the gain of Low EQ
–15...+15dB
HiEQ (Pre High EQ Gain)
Sets the gain of High EQ
–15...+15dB
e
[PHS] LFO (LFO Waveform)
Selects the LFO waveform of the phaser
Tri, Sine
F (LFO Frequency)
Sets the LFO speed
0.02...20.00Hz
f
Manu (Manual)
Sets the frequency to which the effect is applied
0...100
Dep (Depth)
Sets the depth of LFO modulation
0...100
Res (Resonance)
Sets the resonance amount
–100...+100
☞ Fx:023
g
Phs W/D (Phaser Wet/Dry) –Wet...–2:98, Dry, 2:98...Wet
Sets the phaser effect balance
☞ Fx:010, 023
Out (Output Mode) Normal, Wet Inv
Selects the phaser output mode
☞ Fx:067
h
[Routing] CMP→PHS, PHS→CMP
Switches the order of the compressor and phaser connection
☞ Fx:067
Left
Right
Wet / Dry
Wet / Dry
Wet: Mono In - Stereo Out / Dry: Stereo In - Stereo Out
+
Routing
Compressor
LEQ HEQ
EQ Trim
Comp
Output Level
Envelope - Control
Phaser
Phaser
Resonance
LFO: Tri / Sine
Phaser Wet / Dry
Normal
Wet Invert
Output Mode
–
+
