194
046: St.Mod. Delay
(Stereo Modulation Delay)
This stereo delay uses an LFO to sweep the delay time. The
pitch also varies. You will obtain a delay sound with swell
and shimmering. You can also control the delay time using a
modulation source.
b: Dmod
When the modulation source is used for control, this parameter
reverses the left and right modulation direction.
e: LFO Sync, e: Src, f: L Phase, f: R Phase
The LFO can be reset via a modulation source.
The “Src” parameter sets the modulation source that resets the
LFO. For example, you can assign Gate as a modulation source so
that the sweep always starts from the specified point.
“L Phase” and “R Phase” set the phase obtained when the left and
right LFOs are reset. In this way, you can create changes in pitch
sweep for the left and right channels individually.
The effect is off when a value of the modulation source spec-
ified in the “Src” parameter is 63 or smaller, and the effect is
on when the value is 64 or higher. The LFO is triggered and
reset to the “L Phase” and “R Phase” settings when the
value changes from 63 or smaller to 64 or higher.
047: St.DynamicDly
(Stereo Dynamic Delay)
This stereo delay controls the level of delay according to the
input signal level. You can use this as a ducking delay that
applies delay to the sound only when you play keys at a high
velocity or only when the volume level is low.
a
Mod Mode (Modulation Mode) LFO, Dmod
Switches between LFO modulation control and modulation source
control
Src (Source) Off...Tempo
Selects the modulation source that controls delay time
b
Dmod
Reversed L/R control by modulation source
L/R:+/+, L/R:+/–
☞,
Respons (Response) 0...30
Sets the rate of response to the modulation source
c
LFO Wave (LFO Waveform)
Selects LFO Waveform
Tri, Sine
Shape (LFO Shape) –100...+100
Determines how much the LFO waveform is changed
☞ Fx:020
d
LFO Freq (LFO Frequency)
Sets the LFO speed
0.02...20.00Hz
e
LFO Sync
Switches LFO reset off/on
Off, On
☞,
Src (Source) Off...Tempo
Selects the modulation source that resets the LFO
f
L Phase (L LFO Phase) –180...+180
Sets the phase obtained when the left LFO is reset
☞
R Phase (R LFO Phase) –180...+180
Sets the phase obtained when the right LFO is reset
☞
g
L Depth
Sets the depth of the left LFO modulation
0...200
R Depth
Sets the depth of the right LFO modulation
0...200
h
L Dly (L Delay Time)
Sets the left delay time
0.0...500.0
R Dly (R Delay Time)
Sets the right delay time
0.0...500.0
i
L Fb (L Feedback)
Sets the feedback amount of left delay
–100...+100
R Fb (R Feedback)
Sets the feedback amount of right delay
–100...+100
j
W/D (Wet/Dly) –Wet...–1:99, Dry, 1:99...Wet
Sets the balance between the effect and dry sounds
☞ Fx:010,
(Source) Off...Tempo
Selects the modulation source of the effect balance
(Amount)
Sets the modulation amount of the effect balance
–100...+100
Left
Right
Feedback
LFO Phase
Wet / Dry
Wet / Dry
Stereo In - Stereo Out
LFO: Tri / Sine
Modulation Mode
D-mod
LFO
D
-mod
Delay
Delay
L/R: +/+ +/–
LFO Shape
Response
LFO Sync
a
Ctrl Target (Control Target)
Selects from no control, output, and feedback
None, Out, FB
☞
Pol (Polarity)
Reverses level control
+, –
☞
b
Threshold
Sets the level to which the effect is applied
0...100
☞
Offset
Sets the offset of level control
0...100
☞
c
Attack
Sets the attack time of level control
1...100
☞
Release
Sets the release time of level control
1...100
☞
d
L Delay (L Delay Time)
Sets the delay time for the left channel
0.0...680.0ms
e
R Delay (R Delay Time)
Sets the delay time for the right channel
0.0...680.0ms
f
Feedback
Sets the feedback amount
–100...+100
g
HiDamp (High Damp)
Sets the damping amount in the high range
0...100%
☞ Fx:043
LoDamp (Low Damp)
Sets the damping amount in the low range
0...100%
☞ Fx:043
h
Spread –100...+100
Sets the width of the stereo image of the effect sound
☞ Fx:043
i
W/D (Wet/Dly) Dry, 1:99...99:1, Wet
Sets the balance between the effect and dry sounds
(Source) Off...Tempo
Selects the modulation source of the effect balance
(Amount)
Sets the modulation amount of the effect balance
–100...+100
Delay
Left
Right
Feedback
Spread
Wet / Dry
Wet / Dry
Stereo In - Stereo Out
High Damp Low Damp
High Damp
Low Damp
Threshold
+
Delay
FB
Out
Control Target
Attack, Release
Envelope
