Appendices
231
The following functions can be assigned to the REALTIME
CONTROLS [1]-[4] knobs in B mode.
• For Program, Combination, Song, or Song Play mode,
make these settings in 2.2: Ed-Ctrl/Controller page
“Knob B Assign” (2.2–1a).
Realtime Control Knobs B Assign List
Knob 1...4 B Assign
Off No function
Knob Mod. 1 (CC#17) General purpose controller. Alternate Modulation or Effect Dynamic Modulation can be controlled. To use this,
select KnobM1#17 for “AMS,” or Kb1#17 for “Dmod Src.” Simultaneously, CC#17 will be transmitted.
Knob Mod. 2 (CC#19) General purpose controller. Alternate Modulation or Effect Dynamic Modulation can be controlled. To use this,
select KnobM2#19 for “AMS,” or Kb2#19 for “Dmod Src.” Simultaneously, CC#19 will be transmitted.
Knob Mod. 3 (CC#20) General purpose controller. Alternate Modulation or Effect Dynamic Modulation can be controlled. To use this,
select KnobM3#20 for “AMS,” or Kb3#20 for “Dmod Src.” Simultaneously, CC#20 will be transmitted.
Knob Mod. 4 (CC#21) General purpose controller. Alternate Modulation or Effect Dynamic Modulation can be controlled. To use this,
select KnobM4#21 for “AMS,” or Kb4#21 for “Dmod Src.” Simultaneously, CC#21 will be transmitted.
Master Volume Control the volume. Simultaneously, the universal system exclusive message Master Volume [F0H, 7FH, nn, 04,
01, vv, mm, F7H] will be transmitted to adjust the volume of all tracks or timbres (while preserving the volume bal-
ance between tracks or timbres).
Porta. Time (CC#05) Control the portamento time. Simultaneously, CC#5 will be transmitted.
Volume (CC#07) Control the volume. Simultaneously, CC#7 will be transmitted.
IFX Pan (CC#08) Control the panning after the insertion effect. Simultaneously, CC#8 will be transmitted.
Pan (CC#10) Control the oscillator panning. Simultaneously, CC#10 will be transmitted.
Expression (CC#11) Control the expression. Simultaneously, CC#11 will be transmitted.
FX Ctrl 1 (CC#12) Control Effect Dynamic Modulation. When controlling this, set “Dmod Src” to FX1#12. Simultaneously, CC#12 will
be transmitted.
FX Ctrl 2 (CC#13) Control Effect Dynamic Modulation. When controlling this, set “Dmod Src” to FX2#13. Simultaneously, CC#13 will
be transmitted.
Flt Cutoff (CC#74) Control the cutoff frequency of the Filter (low pass filter). Simultaneously, CC#74 will be transmitted.
Flt Reso. (CC#71) Control the resonance of the Filter, or the cutoff frequency of the high pass filter. If the program’s “Type (Filter1/2
Type)” is Low Pass Resonance, the resonance level will be controlled. If it is Low Pass & High Pass, the cutoff
frequency of the high pass filter will be controlled. Simultaneously, CC#71 will be transmitted.
Flt EG Int. (CC#79) Control the EG intensity of the Filter. Simultaneously, CC#79 will be transmitted.
F/A Attack (CC#73) Control the EG attack of the Filter and Amplifier. Simultaneously, CC#73 will be transmitted.
F/A Decay (CC#75) Control the EG decay time and slope time of the Filter and Amplifier. Simultaneously, CC#75 will be transmitted.
F/A Sus. (CC#70) Control the EG sustain level of the Filter and Amplifier. Simultaneously, CC#70 will be transmitted.
F/A Rel. (CC#72) Control the EG release time of the Filter and Amplifier. Simultaneously, CC#72 will be transmitted.
P LFO1 Spd (CC#76) Control the frequency of LFO1. Simultaneously, CC#76 will be transmitted.
P LFO1 Dep (CC#77) Control the LFO1 intensity of the pitch. Simultaneously, CC#77 will be transmitted.
P LFO1 Dly (CC#78) Control the delay of LFO1. Simultaneously, CC#78 will be transmitted.
SW 1 Mod. (CC#80) General-purpose controller. Alternate Modulation or Effect Dynamic Modulation can be controlled. To control
these, set “AMS” or “Dmod Src” to SW 1 #80. Simultaneously, CC#80 will be transmitted.
SW 2 Mod. (CC#81) General-purpose controller. Alternate Modulation or Effect Dynamic Modulation can be controlled. To control
these, set “AMS” or “Dmod Src” to SW 2 #81. Simultaneously, CC#81 will be transmitted.
Foot SW (CC#82) General-purpose controller. Alternate Modulation or Effect Dynamic Modulation can be controlled. To use this,
select FootSW#82 for “AMS,” or FSW#82 for “Dmod Src.” Simultaneously, CC#82 will be transmitted.
MIDI CC#83 (CC#83) General-purpose controller. Alternate Modulation or Effect Dynamic Modulation can be controlled. To use this,
select MIDI CC#83 for “AMS,” or CC#83 for “Dmod Src.” Simultaneously, CC#83 will be transmitted.
MFX Send 1 (CC#93) Control the send level to Master Effect1. Simultaneously, CC#93 will be transmitted.
MFX Send 2 (CC#91) Control the send level to Master Effect2. Simultaneously, CC#91 will be transmitted.
MIDI CC#00...CC#95 The specified MIDI control change (CC#) will be transmitted. If this instrument is set so as to be controlled by the
control change message, the corresponding control will occur.
