68
7.3–1d: MEQ Ctrl
MEQ Ctrl (MEQ Control Ch) [Ch01...16, G ch]
Selects the MIDI channel that will control dynamic
modulation (Dmod) for the master EQ.
G ch: The global MIDI channel “MIDI Channel” (GLOBAL
2.1–1a) will be used for control. Normally you will set this
parameter to G ch.
■ 7.3–1e: UTILITY
☞ “Write Combination,” “Solo Selected Timbre” (1.1–1c),
“Select by Category” (PROG 7.3–1d)
For details on how to select the desired utility function, refer
to “PROG 1.1–1c: UTILITY.”
Copy Master Effect
☞p.41 PROG 7.3–1d
Note, the MIDI control channel that is specified by “MFX1, 2
Control Ch” (7.3–1a) will not be copied.
Swap Master Effect
☞p.41 PROG 7.3–1d
Note, the MIDI control channel that is specified by “MFX1, 2
Control Ch” (7.3–1a) will not be swapped.
7.3–2: MFX1 (Master Effect1)
7.3–3: MFX2 (Master Effect2)
Here you can set the parameters of the “Master Effect1” and
“Master Effect2” effects that were selected in the Setup page
(
☞p.168).
■ 7.3–2(3)a: UTILITY
☞ “Write Combination” (1.1–1c)
7.3–4: MEQ (Master EQ)
The master EQ is a three-band stereo EQ. It is located imme-
diately before the AUDIO OUTPUT (MAIN OUT) L/
MONO and R from the L/R bus, and adjusts the overall
tonal character of the sound (
☞p.220).
■ 7.3–4a: UTILITY
☞ “Write Combination” (1.1–1c)
7.3–2a
7.3–4a
