KUHN MAXIMA 2 - Checking During Sowing

Instructions for work
Precision Seed Drills
MAXIMA 2
103
Checking during sowing:
The seed take-up control can be made while following
the seed drill during a sowing operation.
- Lift the observation flap (1).
- If doubles or misses are noticed during the seed take-
up control, modify the selector position.
- Push knob (1) to place selector (2) in the required
position.
- Repeat procedure until obtaining the right setting.
After checking:
- Lower control hatch.
- Carry out same setting for each seeding unit.
If you notice seed doubles on the disk, move
selector (1) of one or several graduations in
direction 0.
If you notice seed misses on the disk, move
selector (1) of one or several graduations in
direction 30.
The marking enables identical setting of each
seeding unit.
