KUHN MAXIMA 2 - Angle Adjustment

Instructions for work
Precision Seed Drills
MAXIMA 2
81
Angle adjustment
- Loosen U-bolts (1).
- Pivot arm (2) to adjust the disc angle with regards to
the soil type.
- Tighten U-bolts (1).
Repeat procedure on the second side marker.
For models 9 m (29’6’’):
- Loosen U-bolts (1).
- Pivot arm (2) to adjust the disc angle with regards to
the soil type.
- Tighten U-bolts (1).
Repeat procedure on the second side marker.
