KUHN MAXIMA 2 - Suction Adjustment

Precision Seed Drills
112
MAXIMA 2
Instructions for work
Suction adjustment
For 4.40 m to 6 m (14’4’’ - 19’8’’) models
For models 9 m (29’6’’)
The PM20 twin blower is only fitted on seed drills with
9.00 m single bar frame fitted with a 1350 L fertilizer unit.
- Loosen nut (1).
- Position stop in the hole:
• Minimum suction when stop is placed in the hole
bottom position (Position (a)).
Maximum suction when the stop is placed in the hole top
position (Position (b)).
