KUHN MAXIMA 2 - Non Stop Coulter Applicators

Precision Seed Drills
174
MAXIMA 2
Optional equipment
Adjusting the application depth
- Raise the machine.
- Loosen bolts (1).
- Adjust coulter height to obtain the required working
depth.
- Tighten screws (1).
Adjust all applicators to the same setting.
Non stop coulter applicators
Lateral adjustment
The applicator (D) is factory offset with regards to the
seeding line by approximately 50 mm (1.97’’).
Adjusting the application depth
- Raise the machine.
- Remove lynch pin (1) and pin (2).
- Insert pin (2) in one of bracket (3) holes to set the
required working depth.
- Insert and lock lynch pin (1).
Adjust all applicators to the same setting.
The seeding unit setting must be adjusted
according to the sowing conditions (Soil
preparation and nature).
The seeding unit setting must be adjusted
according to the sowing conditions (Soil
preparation and nature).
