KUHN MAXIMA 2 - To Retension the Blower Belt

Maintenance and storage
Precision Seed Drills
MAXIMA 2
203
If the machine is fitted with a microgranulator, a
blower is installed on the front of the vacuum turbine
To retension the blower belt:
- Remove 6 bolts (1).
- Remove guard (2).
- Loosen nuts (1).
- Loosen counter nut (2).
- Rotate screw (3) clockwise to tension the belt.
- Tighten counter nut (2).
- Tighten nuts (1).
The belt tension must be moderate to prevent
overheating.
