Precision Seed Drills
58
MAXIMA 2
Putting into service
The tractor PTO stub must rotate at a speed of 540 min
-1
.
Fitting a pull bar
- Fit pull bar (1) on lower links (2).
- Install spacer (3).
- Insert and lock lynch pin (4).
Proceed the same way on the other side.
Belt and pulley assemblies are available to adapt
the blower speed to the tractor PTO speed.
- 470 min
-1
pulley and belt unit: Kit
no. 1677287
- 870 min
-1
pulley and belt unit: Kit
no. 1676731
- 1000 min
-1
pulley and belt unit: Kit
no. 1676738
The front axle load (1) must never, under any
circumstances, be less than 20% of the
tractor's unladen weight.
The tractor must be fitted with lower link
stabilizers.
A pull bar must be fitted when the machine is
equipped with a semi-automatic attachment
category 2.
