MAXIMA 2
Optional equipment
9. Standard V-shaped roller
Kit no. 1677235:
Standard Rubber V roller 1’’ (a).
Kit no. 1677234:
Standard Rubber V roller 2’’ (b).
Kit no. 1677237:
Standard smooth steel V roller (c).
Kit no. 1677236:
Standard notched steel V roller (d).
The V-shaped roller enables closing and tamping the
seeding line.

Adjustments
Adjusting the tamping pressure
Lever (1) enables adjusting the tamping pressure.
- Position lever (1) in one of the adjusting catches 5:
• To reduce the tamping pressure in F, move
adjustment lever (1) frontwards.
• Mover adjustment lever (1) rearwards to increase
tamping pressure in F.
Adjust all seeding units to the same settings.
