Precision Seed Drills
136
MAXIMA 2
Optional equipment
10. HD V roller
Kit no. 1677241:
HD Rubber V roller 1’’ (a).
Kit no. 1677240:
HD Rubber V roller 2’’ (b).
Kit no. 1677239:
HD smooth steel V roller (c).
Kit no. 1677238:
HD notched steel V roller (d).
The V-shaped roller enables closing and tamping the
seeding line.
Adjustments
Adjusting the tamping pressure
Lever (1) enables adjusting the tamping pressure.
- Position lever (1) in one of the adjusting catches 5:
• To reduce the tamping pressure in F, move
adjustment lever (1) frontwards.
• Mover adjustment lever (1) rearwards to increase
tamping pressure in F.
Adjust all seeding units to the same settings.
