Optional equipment
Precision Seed Drills
MAXIMA 2
175
Machine use
Disengaging the fertilizer
- Remove lynch pin (1).
- Use spacer (3) to stop spacer (2) from moving
sideways.
Safety
When an incident occurs, the safety bolt (3) shears
causing the metering unit to stop.
- Use a punch to remove the remaining shear bolt parts.
- Replace the components.
Hole (4) of larger diameter enables easier
removal of the remaining shear bolt parts.
A full set of replacement components (5) is
positioned on the machine.
Nut (1) Part no. 80200640.
Washer (2) Part no. 80250611.
Safety bolt (3) Part no. N03481B0.
