Optional equipment
Precision Seed Drills
MAXIMA 2
123
4. Furrow opening disk
Kit no. 1676775
Opener disc solo (a).
Kit no. 1676780
Furrow opening disk with star-shaped trash remover (b).
The circular knife coulter facilitates penetration of the
furrow opening disks in plant residues.
The star-shaped trash remover is used to push aside
plant residues in order to prepare for the passage of the
seeding unit.
Adjustment
Furrow opening disk
Height adjustment
- Unscrew the 2 nuts (1) (1 on each side).
- Loosen the 2 screws (2) (1 on each side).
- Position disk holder (3) in one of the holes to increase
or reduce the working depth.
- Tighten the 2 screws (2) (1 on each side).
- Tighten the 2 nuts (1) (1 on each side).
Star shaped trash remover
Height adjustment
- Loosen counter nut (1).
- Turn adjustment screw (2) to increase or reduce
working height.
- Tighten counter nut (1).
The adjustment range is of 25 mm (0.98’’).
The adjustment range is of 80 mm (3.15’’).
